MASCOT ELECTRIC CO., LTD

Handheld Microphone

UF-21B Handheld Microphone
UF-21B Handheld Microphone

UF-21B Handheld Microphone

UF-21B Handheld Microphone

  • Features the MASCOT μ93A dynamic capsule for sweet sound and avoiding handing noise.
  • Optional VC-7 condenser capsule unit delivers delicate and clean voice in high frequency,and is suitable for high voice range performance.
  • The 7-segment LED display shows the current operating channel.
UF-21B
Frequency Range
UHF520 ~ 937.5MHz (Regionally Selected)
Channel Select
Button select
Display
LED shows the battery life
RF Power Output
10mW (max.)
Frequency Stability
±0.005%
Spurious Emission
>60dB below carrier frequency
Battery
DC3V (1.5V x 2 AA batteries)
Current Consumption
120 ± 10mA
Dimension(mm) WxHxD
260 x 56Ø
Net Weight
Approx. 240 g
